2. Remove the CPU card and insert the compact flash card into the CF slot (CN2).
CF card
CF Slot (CN2)
CPU card
PZ-VM21 PCB
Figure 2-95 Installing the CF Card
3. Reinstall the CPU card into the 084M-B1 mother board, and close the CPU Support making sure
tab A locks into place.
SL1100 ISSUE 4.1 (R5.1)
2-66 Installation
