4. Loosen two screws and remove the Front Cover.
Front Cover
Two screws
(with stopper)
Figure 2-35 Removing the Front Cover
5. Using the four hooks on the FM/WM Base mount the IP4WW-Battery Box to the Base.
IP4WW-Battery Box
Square hole
Hooks
Hooks
A
B
C
D
A
a
b
c
d
B
C
D
Figure 2-36 Mounting the Battery Box
SL1100
ISSUE 4.1 (R5.1)
2-26 Installation
