6. Remove two screws and remove the Battery tray bracket.
Two screws
(M3 X 8)
Two screws
(with stopper)
Battery tray cover
Battery tray bracket
Figure 2-21 Remove the Battery Tray Bracket
7. Install two batteries into the Battery tray.
Two screws
(M3 X 8)
Two batteries
Battery tray bracket
Figure 2-22 Battery Installation
SL1100 ISSUE 4.1 (R5.1)
2-18 Installation
