Introduction
SECTION 1 GENERAL INFORMATION
The SL1100 system is designed to support small businesses with simple installation and easy
operation. The small compact KSU comes with an installed CPU and eight digital and four analogue
extension ports and has two stackable slots for further expansion.
The SL1100 provides a maximum of 12 analogue trunks and 24 Multiline terminals, and also equipped
to support Digital Network (BRI/PRI) and IP Trunks (SIP) or IP extensions.
IP/VoIP
PSTN
ISDN
DSS Console
Analog Telephone
FAX
DoorBox
Door Opener
External Paging System
CTI Server
Printer
Relay Control Port
KSU
Remote PC
Embedded VRS/VM
Backup Battery
PC
PCPro/ Web Pro
M ultiline IP Telephone
Extension Port
Office LAN/CTI
Audio Port
External Music Source
(EXMOH, BGM..)
M ultiline Te lephone (2-wire)
(General Purpose Relay)
Figure 1-1 System Configuration
Hardware Manual
1-1
Introduction
1
