SECTION 3 INSTALLING THE EXPANSION INTERFACE CARDS
3.1 General
Up to two expansion interface cards can be installed per KSU.
Table 2-7 Expansion Cards
Expansion Interface
Card
Description Note
IP4WW-080E-B1 8 digital extensions card
IP4[ ]-008E-B1 8 analogue extensions card
IP4WW-000E-B1 0 trunk/extension card for ISDN BRI or Analogue Trunk
IP4WW-4COIDB-B1 4 analogue trunk daughter board (Mount on the 084M-B1/080E-B1/008E-
B1/000E-B1)
IP4WW-2BRIDB-C1 2 Euro-ISDN BRI daughter board (Mount on the 084M-B1/080E-B1/008E-
B1/000E-B1)
IP4WW-1PRIU-C1 1 ISDN PRI card
• The function of IP4WW-000E-B1 card is just a mounting card for the 4COIDB or 2BRIDB.
• The 4COIDB-B1 and 2BRIDB-C1 can be installed in following combinations;
Daughter Board
Option Unit
084M-B1 080E-B1 008E-B1 000E-B1
4COIDB-B1 Yes Yes Yes Yes
2BRIDB-C1 Yes Yes Yes Yes
3.2 Unpacking
Unpack the 080E-B1/008E-B1/000E-B1/4COIDB-B1/2BRIDB-C1/1PRIU-C1 and check it against the
following list. Inspect for physical damage.
Table 2-8 Expansion Card Packing List
Items List of Contents QTY Note
IP4WW-080E-B1 080E-B1 PCB (with PKG Spacer) 1
Nylon Spacers 2
Metal Spacers 2
Screws (with circular washer) 2
IP4[ ]-008E-B1 008E-B1 PCB (with PKG Spacer) 1
Nylon Spacers 2
Metal Spacers 2
Screws (with circular washer) 2
IP4WW-4COIDB-B1 4COIDB-B1 PCB 1
Nylon Spacers 2
4COIDB Label 1
Metal Spacers 1
Screws (with circular washer) 2
ISSUE 4.1 (R5.1) SL1100
Hardware Manual 2-35
