2. Open and remove the Sub-Cover.
Sub-Cover
Sub-Cover
Tab
Tab
Figure 2-89 Removing the Sub-Cover
3. Loosen two screws and remove the Main-Cover.
Two screws
Hooks
Main-Cover
Figure 2-90 Removing the Main-Cover
ISSUE 4.1 (R5.1) SL1100
Hardware Manual 2-63
