8.2 Set Up
Use the Setup menu to configure the E3 transmitter and receiver parameters.
Each configuration parameter is described below:
OFF, 63, 511, 2047, 2-15-1, 2-
21-1, 2-23-1, QRSS, All 0’s, All
1’s, 1:3, 1:7, 1:15, 1:31. The
pattern can also be
configured in Setup.
• Unframed – all
bits used for
data
• AMI Code
• C-Bit
• M-13
Unlimited, 30 s, 1 min, 5 min,
10 min, 30 min, 1hr, 3 hr. 6 hr,
12 hr, 1 day, 2 days, 3 days,
user-defined.
