221
TRAFFIC Tab
Per stream setup:
• Frame Size: User defined from 64 bytes to 9600 bytes.
For Layer 1 Framed and Layer 2 you are able to set
frame size from 48 to 9600 bytes.
• Tx Rate: Utilized Line Rate (URL) %
• Tx FPS: Frame rate (frames per second) value for
desired Tx Rate.
• Total Tx Rate: Sum of all enabled stream’s Tx Rates
(can’t exceed 100%)
• Traffic Shape: Choices are: Constant, Burst, Ramp
• Period: Burst and Ramp shape parameter.
• Duty: Burst duty parameter.
