Net research NetProbe 2000 - T1 Setup Configuration

63
6.2 Set Up
Use the Setup menu to configure the T1 transmitter and receiver parameters listed under the General configuration tab.
This menu also allows you to define the Auto Monitor thresholds used to determine pass/fail results under the
Automonitor tab .
6.2.1 General Configuration Tab
T1 Frame Type
• Unframed – all bits used for data
• ESF-S Extender Super Frame
• SFS
• SF-N
