11.6 Optical Power
After the fiber optic connection is made, press to start measuring optical power. This application provide two types
of information: Optical Power and SFP Details.
11.6.1 Optical Power
Use this menu to measure the Tx and Rx optical power and
transmission rate metrics listed below:
• Frequency (Hz)
• Tx Power (dBm)
• Rx Power (dBm)
• Temperature
• histogram of one above
Tip:
Click in the Details columns to
display a histogram for the
corresponding metric.
