129
Tx Clock
• Internal (rising edge)
• Internal (falling edge)
• Recovered (rising edge)
• Recovered (falling edge)
Rx
Clock
• Internal (rising edge)
• Internal falling edge)
• Recovered (rising edge)
• Recovered (falling edge)
Note: With RS
-
232 Async interface, the setup
parameters Tx Clock and Rx Clock are replaced
with Parity and Stop Bits.
