Net research NetProbe 2000 - Page 198

198
Layer 4
See Rx traffic filtering paragraph in 12.6.1 section to get details of incoming traffic filtering setup.
Now you will need to define RFC 2544 test parameters for the Throughput, Latency, Frame Loss and Burst tests. This
done by entering values (defined below) for the tabs labeled THROUGH, LATENCY, FRAME LOSS and BURST.
Click in the colored
bar to configure the
MAC, IP and UDP Port.
