NL1901ACV Enhanced Hybrid 4G LTE Gateway – User Guide
11 of 146
UG01063 v. 1.0 December 2018
© NetComm Wireless 2018
Media sharing
Connect a USB device to the NL1901ACV gateway, access and share all A/V media and file content with all of the
connected devices in the house in real time. The NL1901ACV becomes the media hub of the house using
DLNA/UPnP standard and enhanced wireless capabilities to create a reliable high-speed home network.
The NL1901ACV has been designed to be placed on a desktop. All of the cables exit from the rear for easy
organization. The display is visible on the front of the NL1901ACV to provide you with information about network
activity and the device status.
Physical dimensions and weight
The table below lists the physical dimensions and weight of the NL1901ACV.
DIMENSIONS
Width 230 mm
Height 200 mm
Depth 75 mm
Weight 562 grams (approx.)
Table 1 – Physical dimensions and weight table
NL1901ACV Default Settings
The following tables list the default settings for the NL1901ACV.
LAN (MANAGEMENT)
Static IP Address
192.168.20.1
Subnet Mask
255.255.255.0
Default Gateway
192.168.20.1
Table 2 – LAN (Management) table
WIRELESS (WIFI)
SSID
(Refer to the included Wireless Security Card)
Security
WPA2-PSK (AES)
Security Key
(Refer to the included Wireless Security Card)
Table 3 – Wireless (WIFI) table
NL1901ACV WEB INTERFACE ACCESS
Username
admin
Password
The NL1901ACV’s Serial Number
Table 4 – NL1901ACV WEB Interface Access table

NetComm NL1901ACV Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1900 Mbit/s
Product type	Tabletop router
Product color	Black
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
4G LTE category	8
Mobile network generation	4G
Output current	2 A
Output voltage	12 V
Power source type	AC
Memory card slot(s)	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK

Weight and Dimensions

Depth	75 mm
Width	230 mm
Height	200 mm
Weight	562 g
