NetComm NL1901ACV - Table 6 - Rear Interface Table

NL1901ACV Enhanced Hybrid 4G LTE Gateway – User Guide
16 of 146
UG01063 v. 1.0 December 2018
© NetComm Wireless 2018
NO.
INTERFACE
DESCRIPTION
3
Telephone 1 and 2
Connect a regular analogue telephone handset here for use
with a VoIP service.
4
Ethernet 1 - 4
Gigabit Ethernet LAN ports. Connect your Ethernet based
devices to one of these ports for high-speed internet access.
5
WAN
Gigabit capable WAN port for connection to a WAN
network. Connect to your Network Termination Device
(NTD) for high-speed internet access.
6
Reset
button Reset unit to Default by inserting a thin metal wire into the
hole and holding the
Reset
button down for 10 seconds
when unit is powered on.
7
USB
Connect an external USB storage device here to use the
Network Attached Storage (NAS) feature of the NL1901ACV.
8
2.4G WPS button
Press the
2.4G WPS
button to activate the WPS PBC pairing
function for the 2.4GHz radio.
9
5G WPS button
Press the
5G WP
S button to activate the WPS PBC pairing
function for the 5GHz radio.
10
USB 1 socket
Connect an external USB storage device here to use the
Network Attached Storage (NAS) feature of the NL1901ACV.
11
Power supply jack
Connection point for the included power adapter. Connect
the power supply here.
Table 6 – Rear interface table
