8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure Switching User Manual204
4. Enter one of the following passwords:
• After registration, enter the local device password.
By default, the local device password is password.
• If you previously managed the switch through the Insight app or Cloud portal, enter
the Insight network password for the last Insight network location.
For information about the credentials, see
Credentials for the local browser interface on
page 32.
5. Click the Login button.
The System Information page displays.
6. Select Switching> Multicast > IGMP Snooping > IGMP Snooping T
able.
The IGMP Snooping Table page displays.
7. In the Search By MAC
Address field, specify the MAC address whose MFDB table entry
you want to view.
Enter six two-digit hexadecimal numbers separated by colons, for example
00:01:23:43:45:67.
8. Click the Go button.
If the address exists, the entry is displayed. An exact match is required.
9. T
o refresh the page with the latest information about the switch, click the Update button.
10. T
o clear all multicast forwarding address entries that were created for IGMP snooping,
click the Clear button.
The following table describes the information in the IGMP snooping table.
Table 44. IGMP Snooping Table information
Field Description
MAC Address The multicast MAC address for which the switch holds forwarding and/or filtering
information. The
format is six two-digit hexadecimal numbers that are separated
by colons, for example, 01:00:5e:45:67:89.
VLAN ID The VLAN ID for which the switch holds forwarding and filtering information.
Type The type of the entry. Static entries are those that are configured by the end
user
. Dynamic entries are added to the table as a result of a learning process or
protocol.
Description The text description of this multicast table entry. The options are Management
Configured, Network Configured, and Network
Assisted.
Interface The interfaces that are designated for forwarding (Fwd) and filtering (Flt) for the
associated address.
