8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure Routing User Manual257
• If you previously managed the switch through the Insight app or Cloud portal, enter
the Insight network password for the last Insight network location.
For information about the credentials, see Credentials for the local browser interface on
page 32.
5. Click the Login button.
The System Information page displays.
6. Select Routingï€ > ARP
> Advanced > ARP Create.
7. In the IP Address field, specify an IP address.
This must be the IP address of a device on a subnet attached to one of the switch's
existing routing interfaces.
8. In the MAC Address field, specify the unicast MAC address of the device.
Enter the address as six two-digit hexadecimal numbers separated by colons, for
example, 00:06:29:32:81:40.
9. Click the Add button.
The static ARP entry is added to the switch.
For information about viewing the new entry and other entries in the ARP cache, see
View the ARP cache on page 254.
View or globally configure the ARP table
You can change the global settings for the ARP table.
To view or configure the ARP table:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser
.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Access the switch on-network and
connected to the Internet on page 19 or Access the switch off-network on page 30.
