8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure Switching User Manual216
The System Information page displays.
6. Select Switchingï€ > Multicast > MLD Snooping > Configuration.
7. Select the MLD Snooping Admin Mode Enable radio button.
By default, the Disable radio button is selected.
8. Click the Apply button.
Your settings are saved.
9. T
o refresh the page with the latest information about the switch, click the Update button.
The following table describes the nonconfigurable MLD Snooping Configuration fields.
Table 46. MLD Snooping Configuration information
Field Definition
Multicast Control Frame Count The number of multicast control frames that were processed by the CPU.
Interfaces Enabled for MLD
Snooping
The interfaces on which MLD snooping is administratively enabled. MLD
snooping must be enabled globally and on an interface for the interface to
be able to snoop MLD packets to determine which segments must receive
multicast packets directed to the group address.
VLAN IDs Enabled For MLD
Snooping
The VLANs on which MLD snooping is administratively enabled.
Configure MLD snooping for interfaces
To configure MLD snooping for interfaces:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Access the switch on-network and
connected to the Internet on page 19 or Access the switch off-network on page 30.
