Maintain or Troubleshoot the Switch User Manual458
The default value is 33434. The range is 1–65535.
14. In the Size field, enter the size of the probe packets.
The default value is 0. The range is 38 to 32768.
15. From the Source menu, as an option, you can select the IP address or interface that must
be used to send probe packets:
• None. The source address of the probe packet is the address of the default egress
interface.
• IP Address. The source IP address that must be used when probe request packets
are sent. With this selection, the IP Address field displays and you must enter the
IPv4 address that must be used as the source.
• Interface. The interface that must be used when probe request packets are sent. The
Interface menu displays, but the only available selection from the menu is Network.
16. Click the Apply button.
A traceroute request is sent to the specified IP address or host name. The results are
displayed below the configurable data in the Results field.
Send an IPv6 traceroute
You can configure the switch to send a traceroute request to a specified IPv6 address or host
name. You can use this to discover the paths that packets take to a remote destination.
When you send a traceroute, the switch displays the results below the configurable data.
If a reply to the traceroute is received, the following message displays:
traceroute to x:y::z:w (x:y::z:w), maxTTL hops max, size byte packets
initTTL x:y::z:w (x:y::z:w) 0.000 ms * 0.000 ms
initTTL+1 x:y::z:w (x:y::z:w) 0.000 ms * 0.000 ms
initTTL+2 x:y::z:w (x:y::z:w) 0.000 ms * 0.000 ms
To send an IPv6 traceroute:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the switch on-network and
connected to the Internet on page 19 or Access the switch off-network on page 30.
The login page displays.
If the NETGEAR Business page displays, see Register and access the switch with your
NETGEAR account on page 34.
