8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure Switching User Manual163
5. Click the Login button.
The System Information page displays.
6. Select Switchingï€ > VLAN >
Advanced > Protocol Based VLAN Group Configuration.
7. In the Group ID field, enter a number to identify the group.
The number must be in the range from 1 to 128.
8. In the Group Name field, enter a name for the new group.
You can enter up to 16 characters.
9. In the Protocol field, enter one or more protocols that must be associated with the group.
You can enter keywords such as arp, ip, and ipx. Separate keywords with a comma. Y
ou
can also enter hexadecimal or decimal values in the range from 0x0600 (1536) to
0xFFFF (65535).
10. In the VLAN ID field, enter the VLAN ID.
The ID can be any number in the range from 1 to 4093. All the ports in the group assign
this VLAN ID to untagged packets received for the protocols that you included in this
group.
11. Click the Add button.
The protocol-based VLAN group is added to the switch.
The Ports field displays all the member ports that belong to the group.
Configure protocol-based VLAN group membership
To configure protocol-based VLAN group membership:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Access the switch on-network and
connected to the Internet on page 19 or Access the switch off-network on page 30.
The login page displays.
If the NETGEAR Business page displays, see
Register and access the switch with your
NETGEAR account on page 34.
