8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Configure Switching User Manual164
4. Enter one of the following passwords:
• After registration, enter the local device password.
By default, the local device password is password.
• If you previously managed the switch through the Insight app or Cloud portal, enter
the Insight network password for the last Insight network location.
For information about the credentials, see
Credentials for the local browser interface on
page 32.
5. Click the Login button.
The System Information page displays.
6. Select Switchingï€ > VLAN >
Advanced > Protocol Based VLAN Group Membership.
The previous figure shows the Protocol Based VLAN Group Membership page for
model GS110TPv3.
7. From the Group ID menu, select the protocol-based VLAN group ID.
The Group Name field shows the name that is associated with the group.
8. In the Ports table and LAG table,
click each port and LAG that you want to include in the
protocol-based VLAN group.
A protocol-based VLAN group can include both port and LAGs. A selected port or LAG is
displayed by a check mark.
9. Click the Apply button
Your settings are saved.
10. T
o display the current numbers in the selected protocol-based VLAN group, click the
Current Members button.
