8-Port Gigabit (PoE+) Ethernet Smart Managed Pro Switch with (2 SFP or 2 Copper Ports and)
Cloud Management
Manage Device Security User Manual373
The previous figure shows the MAC Binding Configuration page for model GS110TPv3.
7. From the ACL ID menu, select an
ACL.
The fixed selection from the Direction menu is Inbound, which means that MAC
ACL
rules are applied to traffic entering the interface.
8. In the Sequence Number field, optionally specify a number to indicate the order of the
access list relative to other access lists already assigned to the interface and direction.
A low number indicates high precedence order. If a sequence number is already in use
for the interface and direction, the specified access list replaces the currently attached
access list using that sequence number
. If you do not specify the sequence number, a
sequence number that is one number greater than the highest sequence number
currently in use for the interface and direction is used. The range is from 1 to
4294967295.
9. T
o add the selected ACL to a port or LAG, in the Ports table or LAG table, click the port or
LAG so that a check mark displays.
You can add the ACL to several ports and LAGs.
The Ports and LAG tables display the available interfaces for ACL bindings. All
nonrouting physical interfaces, VLAN interfaces, and interfaces participating in LAGs are
listed.
10. Click the Apply button.
Your settings are saved.
The following table describes the information displayed in the Interface Binding Status table.
Table 69. Interface Binding Status table
Field Description
Interface The interface of the ACL assigned.
Direction The selected packet filtering direction for the ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID The ACL name identifying the ACL assigned to the selected interface and direction.
Sequence Number The sequence number signifying the order of the specified ACL relative to other ACLs
assigned to the selected interface and direction.
