Virtual Private Networking Using IPSec Connections

286

ProSecure Unified Threat Management (UTM) Appliance

Note: The IKE policy settings that are explained in the following table are

specifically for a Mode Config configuration. Table 64 on page 266

explains the general IKE policy settings.

Table 70. IKE policy settings for a Mode Config configuration

Setting Description

Mode Config Record

Do you want to use

Mode Config Record?

Select the Yes radio button.

Note: Because Mode Config functions only in Aggressive mode, selecting the Yes

radio button sets the tunnel exchange mode to Aggressive mode. Mode Config

also requires that both the local and remote endpoints are defined by their FQDNs.

Select Mode

Config Record

From the drop-down list, select the Mode Config record that

you created in step 4 on page 284. This example uses NA

Sales.

General

Policy Name A descriptive name of the IKE policy for identification and management purposes.

This example uses ModeConfigNA_Sales.

Note: The name is not supplied to the remote VPN endpoint.

Direction / Type Responder is automatically selected when you select the Mode Config record in

the Mode Config Record section of the screen. This ensures that the UTM

responds to an IKE request from the remote endpoint but does not initiate one.

Exchange Mode Aggressive mode is automatically selected when you select the Mode Config

record in the Mode Config Record section of the screen.

Local

Select Local Gateway

(multiple WAN port

models only)

Select a WAN interface from the drop-down list to specify the WAN interface for the

local gateway.

Identifier Type From the drop-down list, select FQDN.

Note: Mode Config requires that the UTM (that is, the local endpoint) is defined by

an FQDN.

Identifier Enter an FQDN for the UTM. This example uses router.com.
