Configure Routing
202
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
IpInUnknownProtos The number of locally addressed datagrams received successfully but
discarded because of an unknown or unsupported protocol.
IpInDiscards The number of input IP datagrams for which no problems were encountered
to prevent their continued processing, but that were discarded (for lack of
buffer space). This counter does not include any datagrams discarded while
awaiting re-assembly.
IpInDelivers The total number of input datagrams successfully delivered to IP user
protocols (including ICMP).
IpOutRequests The total number of IP datagrams that local IP user protocols (including
ICMP) supplied to IP in requests for transmission. This counter does not
include any datagrams counted in ipForwDatagrams.
IpOutDiscards The number of output IP datagrams for which no problem was encountered
to prevent their transmission to their destination, but that were discarded for
reasons such as lack of buffer space. This counter would include
datagrams counted in ipForwDatagrams if any such packets met this
(discretionary) discard criterion.
IpOutNoRoutes The number of IP datagrams discarded because no route could be found to
transmit them to their destination. This counter includes any packets
counted in ipForwDatagrams that meet this no-route criterion. This includes
any datagrams that a host cannot route because all of its default gateways
are down.
IpReasmTimeout The maximum number of seconds for which received fragments are held
while they are awaiting reassembly at this entity.
IpReasmReqds The number of IP fragments received that were reassembled at this entity.
IpReasmOKs The number of IP datagrams successfully reassembled.
IpReasmFails The number of failures detected by the IP reassembly algorithm (for
whatever reason: timed out, errors, and so on). This is not necessarily a
count of discarded IP fragments since some algorithms can lose track of the
number of fragments by combining them as they are received.
IpFragOKs The number of IP datagrams that were fragmented at this entity.
IpFragFails The number of IP datagrams that were discarded because they needed to
be fragmented at this entity but could not be, for reasons such as their Don't
Fragment flag was set.
IpFragCreates The number of IP datagram fragments that were generated as a result of
fragmentation at this entity.
IpRoutingDiscards The number of routing entries that were discarded even though they were
valid. One possible reason for discarding such an entry could be to free up
buffer space for other routing entries.
IcmpInMsgs The total number of ICMP messages that the entity received. This counter
includes all those counted by icmpInErrors.
Table 55. IP Statistics information (continued)
Field Description

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
