Link Layer Discovery Protocol
218
"FD 100/320Gbps NT and FX NT IHub System
Basics, Management and OAM Guide"
3HH-11982-AAAA-TQZZA Issue: 10
Table 251 describes the LLDP Local System Information output fields.
Table 251 LLDP Local System Information output fields
Table 252 describes the LLDP Destination Addresses output fields.
Table 252 LLDP Destination Addresses output fields
Table 253 describes the LLDP Remote Statistics output fields.
Table 253 LLDP Remote Statistics output fields
Message Fast Tx Shows the message-fast-tx configured to set the duration of the fast transmission
period for LLDP PDUs.
Message Fast Tx Init Shows the message-fast-tx configured to set duration of the fast transmission period
for LLDP PDUs.
Admin Enabled Shows the current system-wide LLDP enable status configured.
Label Description
Chassis Id Subtype Shows the chassis ID subtype used in ISAM (for ISAM the subtype is 4 or MAC
address type)
Chassis Id Shows the chassis ID for ISAM used for LLDP (for ISAM this is the system base
MAC address)
System Name Shows the system name used for LLDP (for ISAM it is FAD chassis by default; can
be changed by using the “configure system id <string>” command)
System Description Shows the system description for ISAM:
<Release Number> <Shelf Name> <NT Card Name>.
All rights reserved. All use subject to applicable license agreements.
Capabilities Supported Shows the forwarding capabilities for ISAM. For ISAM, it is “bridge router”
Capabilities Enabled Shows the forwarding capabilities enabled in ISAM. For ISAM, it is “bridge router”
Label Description
Index 1 Shows the Reserved Multicast Address used for Nearest Bridge LLDP PDUs.
Index 2 Shows the Reserved Multicast Address used for Nearest Non TPMR Bridge LLDP
PDUs
Index 3 Shows the Reserved Multicast Address used for Nearest Customer LLDP PDUs.
Label Description
Last Change Time Shows the last time (time since Apoch) wherein a remote LLDP information is
inserted, removed or aged out in the local MIB table.
(1 of 2)
Label Description
(2 of 2)
