7705 SAR Interfaces
588
Interface Configuration Guide
3HE 11011 AAAC TQZZA Edition: 01
3.14.2.1.3 Show External Alarms Commands
external-alarms
Syntax external-alarms alarm [alarm-id]
external-alarms input [alarm-input] [detail]
external-alarms name [name-string] [detail]
external-alarms output [alarm-output] [detail]
Context show
Description This command displays external alarm information for 7705 SAR Ethernet ports, for the
Auxiliary Alarm card, or the External Alarms connector on the Fan module of the 7705 SAR-8,
the Alarm module of the 7705 SAR-18, or the faceplate of the 7705 SAR-M, 7705 SAR-X,
7705 SAR-H, or 7705 SAR-Hc chassis.
Parameters alarm-id — the alarm identifier
Values 1 to 2147483647
alarm-input — identifies the alarm input
• for Ethernet ports, the format is:
port-slot/mda/port [name]
• for the Auxiliary Alarm card, the format is:
alarm-slot/mda.{d | a}-alarm-num [name]
• for the four alarm inputs on an External Alarms connector, the format is:
alarm.d-alarm-num [name]
where:
slot = card slot number for IOM (always 1 on the 7705 SAR)
mda = Ethernet adapter card or Auxiliary Alarm card slot number (for Ethernet
modules or ports on platforms with no card slots, the mda slot number is
preconfigured)
port = port number for Ethernet ports
d = digital input
a = analog input
alarm-num
= alarm port number (1 to 24 for digital on the Auxiliary Alarm card, 1
to 4 for digital on the four chassis alarm inputs, 1 or 2 for analog)
name = optional name assigned to the input
name-string — the name for the input port or output relay (maximum of 15 characters)
Note: If you configured a name for the alarm-input using the name option (see input
command), you can use the configured name instead of the alarm-input identifier in the
show command.
