Interface Configuration Guide 7705 SAR Interfaces
Edition: 01 3HE 11011 AAAC TQZZA 589
alarm-output — the output relay identifier, in the following format:
relay-slot/mda.d-relay-num
where:
slot = slot number of the card in the chassis (always 1 on the 7705 SAR)
mda = Auxiliary Alarm card slot number
d = digital output
relay-num = output relay number (1 to 8)
detail — displays detailed information for the external alarms
Output The following outputs are examples of external alarm information:
• Specific Alarm (Output Example, Table 46)
• External Alarm Input (Output Example, Table 47)
• External Alarm Input Detail (Output Example, Table 48)
• External Alarm Output (Output Example, Table 49)
• External Alarm Output Detail (Output Example, Table 50)
• External Alarm Name (Output Example, Table 51)
Output Example
*A:ALU-1># show>external-alarms# alarm 1
===============================================================================
Alarm 1 Detail
===============================================================================
Admin Status : up State : ok
Severity : critical
Description : N/A
Thresholds
Analog Voltage : 0.000 V Operation : gt
Actions
Log Alarm : yes
Chassis Alarming : yes
--------------------------------------------------------------------
Trigger Type Admin Value Threshold State
--------------------------------------------------------------------
alarm-1/1.a-2 analog-in up 0.0 V ok
--------------------------------------------------------------------
Triggers Req'd : any
===============================================================================
*A:ALU-1># show>#
Note: If you configured a name for the alarm-output using the name option (see output
command), you can use the configured name instead of the alarm-output identifier in the
show command.
