Nordson Asymtek X-1020 User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-45 P/N 196515 (Revision A)
Diagram Sheet 2-5-6
Operation of Stop Pin and Lift Tables/Clamp Bars
Board Sensor
y Detects presence of workpieces in
pre- dispense, dispense, and post-
dispense stations. Signals are routed
to Conveyor/Heater Controller via
Conveyor Interconnect PWA.
Conveyor Interconnect PWA
y Passively routes signals between
Conveyor Controller and Pneumatic
Solenoids/Board Sensors..
Conveyor Controller
y Receives Board Sensor input.
y Performs station timing functions.
y Generates outputs to solenoid valves.
y Communicates conveyor states and status to
FmNT.
Conveyor Interconnect PWA
y Passively routes signals between
Conveyor Controller and Pneumatic
Solenoids.
Pneumatic Solenoid
y Activates to raise/lower Stop Pins and
Lift Tables/Clamp Bars.
