Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-116 P/N 196515 (Revision A)
Exercise Sheet 2-13-1
Installing a Needle Heater
1. Verify that the Dispensing Head is at the top of its Z-axis travel and at the front
of the dispensing chamber.
If not in position, use the Position Controls to move the Dispensing Head as
specified in the Operation section of this manual.
2. Press OFF (0) on the Operator’s Console and open the Hatch.
3. Loosen the thumbscrew on the side of the heating element (
See Error!
Reference source not found. on page Error! Bookmark not defined.).
4. Slide the heating element onto the Luer lock adapter.
5. Tighten the thumbscrew on the side of the heating element.
DO NOT over-tighten the thumbscrew. Over-tightening can damage the
needle.
6. Connect the Needle Heater Power Cable to the power outlet labeled “Needle
Heater” on the electrical/pneumatic bulkhead next to the Dispensing Head (
See
Error! Reference source not found. on page Error! Bookmark not
defined.).
7. Close the Hatch and turn ON the dispensing system by pressing ON (I) on the
Operator’s Console.
