Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-94 P/N 196515 (Revision A)
Exercise Sheet 2-11-1
Configuring the Height Sensor
1. In the Main Window, click on Configuration.
2. Select Setup Height Sensor from the Configuration Menu.
 The Height Sensor Configuration box opens
3. Click on the down arrow under Height Sensor Type and select RT from the drop
down menu.
4. Select a Mode.
 You have three options available: Height sense always, Selective height
sense and Height sense on command. Click on Help for detailed explanations
of all available options.
 Adjusting the Z-Axis velocity and acceleration can improve throughput by
decreasing the amount of time it takes to take a height sense measurement. For
example, a slow velocity (1 in/sec) with a low acceleration value (<250 in/sec2)
produces the most accurate height sensing measurements. Velocities above 2
inches per second and accelerations above 300 in/sec2 can result in large
repeatability errors.
5. Click on OK.
