Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-71 P/N 196515 (Revision A)
Exercise Sheet 2-8-3
Checking Fixed-Width Conveyor Clearance
Perform the following procedure only if your dispensing system has
been configured for an application that requires a fixed conveyor width.
DO NOT perform the procedure for adjustable-width conveyor
configurations
.
1. Verify that electrical cables and pneumatic lines near the conveyor are not in
danger of being pinched or snagged during conveyor operation.
2. In the FmNT Tools Window, click on the
Jog icon .
3. In the Jog Commands dialog box, click on Conveyor.
4. Open the dispensing system hatch.
 The green beacon light should go OFF and the yellow beacon light should
come ON.
5. In the Jog Commands dialog box, click on both the slow
and the fast
X-axis jog buttons to try to move the conveyor belt in both directions.
 There should be no movement of the conveyor belt.
6. Close the hatch.
7. In the Jog Commands dialog box, click on both the slow
and the fast
X-axis jog buttons to move the conveyor belt in both directions.
 The conveyor belt should move smoothly in both directions with no slipping
on its pulleys.
8. Close the Jog Commands dialog box to return to the Tools Window.
9. In the Tools Window, click on the Return to Main Window icon
.
To Next Page
