Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-46 P/N 196515 (Revision A)
Exercise Sheet 3-8-3
Reconnecting the DP-3000
1. Open the swinging bracket by pressing up on the red swinging bracket latch and
gently pulling out on the swinging bracket.
2. Flip the yellow stopcock lever forward to release the stopcock.
3. Flip the green chamber retention lever up 90°.
4. Press down on the sliding bracket until you feel the blue detent lever click that
locks the bracket in the down position.
5. Gently slide the chamber retention slide out to the open position.
6. Assemble the pumping chamber.
7. Insert the pumping chamber into the DP-3000.
8. The prime port faces left, away from the chamber retention slide. The pumping
chamber should fit over the piston and snugly up against the piston opening.
9. Push the chamber retention slide in to lock the pumping chamber in place.
10. Place the stopcock into the Luer clamp block.
11. Make sure that the stopcock sits flush on the face of the Luer clamp block.
12. Perform the following steps to close the DP-3000:
 Pull out on the blue detent lever to unlock the sliding bracket.
 Gently push up on the sliding bracket, making sure that the bottom of the
pumping chamber fits into the top of the stopcock.
 Rotate the green chamber retention lever down 90° to lock the sliding
bracket in place.
 Close the swinging bracket, making sure that the stopcock fits into the
grooves on the stopcock actuator.
- You will need to push up on the red swinging bracket latch and release it
when the swinging bracket closes to lock it in place.
 Rotate the yellow stopcock lever back 180° to lock the stopcock in place.
 Flip the orange locking lever on the pump all the way up. This is the
unlocked position.
 Slide the pump all the way down the track of the dovetail receiver assembly
on the dispensing head.
 The bottom surface of the pump should rest against the dovetail mating
stop at the bottom of the dovetail assembly.
 Flip the orange locking lever 190° (down) to lock the pump into place.
