Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-35 P/N 196515 (Revision A)
Exercise Sheet 3-7-1
Removing the Conveyor Belts
This procedure should only be performed by a trained service technician.
Only one Belt should be removed at a time. Use the other Belt as a reference
for proper orientation of the Belt being replaced.
For ease of reinstallation, you should note the locations and orientations of
rail-mounted components before removing them. All components and fasteners
removed during this procedure should be retained in an orderly manner and in a safe
location for reinstallation or shipment back to Asymtek.
Tools and Materials Needed:
• 4-mm Hex Key • Soft Cloth and Cotton Swabs
• 2.5-mm Hex Key • Two P/N 01-0306-00 Conveyor O-rings
• Isopropyl Alcohol • Removable Thread Locker (P/N 40-0019)
• Phillips Head Screwdriver • Torque Wrench
1. Move the dispensing head to the Home position.
2. Use the Jog Controls to move the rear Conveyor Rail to the extreme back of the
dispensing chamber.
3. Perform a Service Shutdown as specified in Information Sheet 1-3-2 on page
1-11.
4. Open the Hatch.
5. Remove any rail-mounted components that interfere with belt
removal/replacement.
If Stop Pins interfere, use a 2.5-mm hex key to remove the Stop Pins along
the length of the Conveyor Rails.
If Clamp Bars interfere, use a Phillips head screwdriver to remove them.
6. Slide the old belt off the Conveyor Pulley Tires and discard.
To Next Page
