Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-27 P/N 196515 (Revision A)
Information Sheet 2-4-2
Pneumatic Distribution (Continued)
D. Valve Pressure Regulator and Gauge
1. The Valve Pressure Regulator and Gauge is located behind the lower front
cabinet door and controls the air pressure that actuates some dispense
valves (DJ-2000, DP-3000) during dispensing.
2. It can also be used to toggle the valve on and off or to assist in the valve
refill process, depending on the valve configuration.
3. Routing is identical to that for the Fluid Pressure Regulator and Gauge.
E. Tooling Air Pressure Regulator and Gauge
1. The Tooling Pressure Regulator and Gauge is located behind the lower front
cabinet door and controls air pressure for Stop Pins and Lift Tables or Clamp
Bars.
2. Tooling pressure pneumatic lines are routed under the conveyor to the
pneumatic valve manifold located in the rear of the dispense chamber on top
of the conveyor base plate.
3. For systems with Impingement Heaters, the air is routed from a six-port
junction from the servo shelf to a manual valve located behind the lower
front cabinet door. The air routing then goes to the impingement flowmeter
located just below the manual valve ending at that station’s heater tooling.
F. Dual-Action Solenoid
1. The Dual-Action Valve is located at the right rear of the Servo Shelf.
2. Air from the Dual Action Valve leaves in two 1/8” pneumatic lines, one black
and one blue. Both hoses lead to the Dispensing Head bulkhead via the Cat
Track.
The blue hose connects to the T/ON port; the black hose connects to the
T/OFF port.
These ports are used on systems equipped with Dual-Action Dispensing
Heads to lower Valve 2 when in use.
