Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 5-15 P/N 196515 (Revision A)
Lesson 5-4
Removing and Replacing the Scale
A. Introduction
Occasionally the Service Technician may need to replace the scale on the X-1020
only. The following lesson outlines the procedure to remove and replace the
scale. Remember that the scale is a precision instrument with delicate
components. It is imperative to handle scale components with care or they may
be damaged.
B. Enabling Objective
5.4 Perform the procedure to remove and replace the scale.
C. Topic Outline
1. Introduction
2. Overview
 Removing the Scale
 Installing the Scale
3. Summary and Review
