Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-85 P/N 196515 (Revision A)
Lesson 2-10
Linear Encoders
A. Introduction
Linear encoders are mounted on each axis and keep track of the actual
dispensing head position. If the dispensing head starts and then stops or loses
its position, it may be necessary to adjust the encoders.
B. Enabling Objective
2.10 Perform the procedure to adjust the Linear Encoders.
C. Topic Outline
1. Introduction
2. Overview
 Linear Encoders
 Linear Encoder Calibration
3. Summary and Review
