Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-164 P/N 196515 (Revision A)
Information Sheet 2-18-3
PMAC Plot (Continued)
D. Analyzing Data
1. For every acceleration move, there is an equal and opposite deceleration
peak for each move.
2. Both acceleration and deceleration peaks will match in magnitude. It’s
possible to have a negative peak acceleration and positive peak deceleration
if the move is going backwards.
3. It’s essential to understand the direction of positive counts in each axis. As
operator faces machine:
X-motor moves positive counts toward the right, negative counts toward
the left
Y-motor moves positive counts toward the back of machine, negative
counts towards the front of the machine.
Z-motor moves positive counts going down and negative counts while
moving up.
A Following Error should be analyzed at the end of deceleration move. An
ideal following error would be 0.
E. Saving and Printing Data
1. Load Word Pad.
Press [Ctrl]-[Esc] keys
Select Start, Programs, Accessories, Word Pad.
2. [Alt]-[Tab] back to PMACPLOT window.
3. Maximize plot window.
4. Press [Alt]-Print Screen. (This performs a screen capture).
5. Select Word Pad on toolbar.
6. Press Align Center button.
7. Type: filename (see step 11) [enter], FmNT Program Name [enter], and Date
(yy-mm-dd) [enter].
8. Select File, Page Setup, select Landscape, set Top Margin to .5”, press
OK.
9. Press [Ctrl)-V. (This performs a paste function)
10. Select File, Save As and enter a filename.
11. Filename format should be:
snxxxx_description of move.doc
where
xxxx
is
serial number of the machine.
12. If a color printer is available, select File, Print, Printer, click OK.
13. You may e-mail or send your file to Asymtek Field Service.
