Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 5-2 P/N 196515 (Revision A)
Information Sheet 5-1-1
Removing and Replacing Fuses
A. Replaceable Fuses
AXIOM X-1000 REPLACEABLE FUSES
Part
Number
Qty. Location Rating Size
Mount
Type
55-5635 1
Conveyor Controller Power
Supply
5A, 250V, Slow 0.25 x 1.25 in. Board
55-5322 1 Main Interface PWA 2A, 250V, Fast 5 x 20 mm Board
194018 1 Main Interface PWA 5A, 250V, Fast 5 x 20 mm Board
194023 2*
Servo Supply Transformer Power
Inlet
8A, 250V, Fast 5 x 20 mm Box
194023 8 Front of Conveyor Controller 8A, 250V, Fast 5 x 20 mm Panel
195967 1 Main Interface PWA
0.25A, 250V,
Slow
5 x 20 mm Board
B. Board Mounted Fuses
1. These glass fuses are mounted in holders on the Computer Main Interface
PWA and on the Conveyor Controller Power Supply PWA.
2. The fuses protect the components from damage caused by electrical
overloads.
C. Panel Mounted Fuses
1. These glass fuses are located on the front panel of the Conveyor Controller.
2. The fuses protect the Controller from damage caused by power surges from
the Heater Tooling.
D. Box Mounted Fuses
1. There is a glass box-mounted fuse in a drawer located on the Servo Shelf
Transformer Power Inlet.
2. The fuse protects the Servo Supply Transformer and Servo Shelf electrical
components from damage caused by power surges. A spare fuse is also in
the drawer.
E. Fuse Replacement Precautions
1. The circuit board and its components are susceptible to damage by
electrostatic discharge. Observe all ESD protection protocols while
performing this procedure.
2. Fuse replacement should only be performed by a trained service technician.
