Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 2-73 P/N 196515 (Revision A)
Diagram Sheet 2-8-2
Conveyor Rail Level Measurement Locations
Item Description
1 Approximate Measurement Location (Order Shown: A, B, C, etc.)
2 Rear Conveyor Rail
3 Stop Pin
4 Front Conveyor Rail
5 Part Sensor
5
3
2
1b
1a
1e
1d
1c
4
1f
