Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 3-57 P/N 196515 (Revision A)
Diagram Sheet 3-8-8
DJ-2000 – Disassembly for Cleaning
15
10
5
Micrometer
Lock Nut
Preload
Screw
Preload Lock
Nut
Solenoid
Valve
Needle
U-Cup Seal
Black (Kalraz)
O-Ring
Extension
Seat
Nozzle
Hex Screw
s
Needle Heate
r
Conductive
Grease
Extension
Filliste
r
Scre
w
Lowe
r
Bod
y
Purge Scre
w
Syringe Lue
r
Loc
k
Upper Bod
y
Dispense Ca
p
Micromete
r
A
ssembl
y
