Nordson Asymtek X-1020 User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-17 P/N 196515 (Revision A)
Reconnect the Cable (P/N 06-
4515-00) to the Power Control
outlet on the Power Manager.
Is the Vent Switch
Faker connected?
Power Manager
(P/N 62-1620-01) has
failed.
Verify the Vent Switch Faker
(P/N 194034) is connected to J9.
Install Vent Switch Faker
(P/N 19034)
Pin 3 to Pin 4
Pin 1 to Pin 2
Pin Connections
Verify the continuity of the Vent Switch Faker
pins as specified below:
Is there continuity
between the pins?
Vent Switch Faker
(P/N 19034) has failed.
Switch the Main Circuit
Breaker to the OFF (0)
position.
Yes
No
Yes No
Reconnect the Cable (P/N 06-
4515-00) to the Power Control
outlet on the Power Manager.
Is the Vent Switch
Faker connected?
Power Manager
(P/N 62-1620-01) has
failed.
Verify the Vent Switch Faker
(P/N 194034) is connected to J9.
Install Vent Switch Faker
(P/N 19034)
Pin 3 to Pin 4
Pin 1 to Pin 2
Pin Connections
Verify the continuity of the Vent Switch Faker
pins as specified below:
Is there continuity
between the pins?
Vent Switch Faker
(P/N 19034) has failed.
Switch the Main Circuit
Breaker to the OFF (0)
position.
Yes
No
Yes No
Diagram Sheet 4-2-10
System Power Fault Isolation Procedure - Vent Switch Faker Verification
