Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 5-6 P/N 196515 (Revision A)
Exercise Sheet 5-2-1
Removing a Conveyor Belt
Tools and Materials Needed:
• 4-mm Hex Key • Soft Cloth and Cotton Swabs
• 2.5 mm Hex Key • Two P/N 01-0306-00 Conveyor O-Rings
• Isopropyl Alcohol • Removable Thread Locker (P/N 40-0019)
• Phillips Head Screwdriver • Torque Wrench
Only one Belt should be removed at a time. Use the other Belt as a
reference for proper orientation of the Belt being replaced.
All components and fasteners removed during this procedure should be
retained in an orderly manner and in a safe location for reinstallation
or shipment back to Asymtek.
1. Move the dispensing head to the Home position.
2. Use the Jog Controls to move the rear Conveyor Rail to the extreme back of the
dispensing chamber.
3. Perform a Service Shutdown as specified in the Safety section of this manual.
4. Open the Hatch.
5. Remove any rail-mounted components that interfere with belt
removal/replacement.
If Stop Pins interfere, use a 2.5-mm hex key to remove the Stop Pins along
the length of the Conveyor Rails.
If Clamp Bars interfere, use a Phillips head screwdriver to remove them.
For ease of reinstallation, you should note the locations and orientations of
rail-mounted components before removing them.
6. Slide the old belt off the Conveyor Pulley Tires and discard.
This procedure should only be performed by a trained service
technician.
