Hub Module / Identification
1) Identifies HUB module in G3 System.
Hub Module / Description
2) Identifies Module type.
Hub Module / Advanced Settings
3) Allows the user to set/configure module
parameters.
Press the SET button to advance to the first
parameter/setting.
A) Press the SET button to enter the Set
Brightness sub-menu and highlight the
selection.
B) Press the NEXT button to select the desired
Brightness selection, (Low, Medium, High).
C) Press the SET button to slect the desired
Brightness level.
Screen Jumps to Next Parameter/Selection
D) Press the SET button to enter the Flip
Display sub-menu and highlight the selection.
E) Press the NEXT button to select the desired
Flip Display selection, (Normal, Flipped).
F) Press the SET button to select the desired
display orientation.
G) Press NEXT to advance to the next parameter
selection (Branch Reserve
To Next Page
