Sub-Bus Valve Module (without distribution and I/O)
• COMM - 5 pin M12 male Sub-Bus communication connector.
• Must be connected to the SUB-BUS OUT connector of the previous assembly
• Carries 24 VDC power for electronics of module
• POWER - 4 pin M12 male power connector.
• Power is required for Outputs
• Used to distribute Valves on the Sub-Bus.
• Does not allow connection to G3 I/O modules.
