45530603TH Rev.2
7-6
Oki Data CONFIDENTIAL
7. PERIODIC MAINTENANCE
(9) Gently wipe the surface of the LED head with soft tissue paper or cloth.
(10) Set the belt unit to the printer, and push it in firmly.
(11) Raise the belt unit left/right lock lever, rotate the lock lever knob (blue) to the right to
lock.
❶
❶
❷
❷
Note! Ensure not to touch or damage the Belt surface.
(12) Return the center lever (blue) to the left.
To Next Page
