6.2 BAPR2 MAIN BOARD
The BAPR2 board can be configured with a double interface (as shown in the figure) or without parallel
interface connector and circuitry. The two board versions also have different codes.
6.2.1 BOARD VIEW AND LOCATION OF CONNECTORS
Fig. 6-1 BAPR2 Main Board Installed in the Printer
J85
J92
J97
J34
J95
J93
J77
J49J95
J98
J86
J91
J33
