Service Manual
683311W
4-3
4.3.2 CONFIGURATION PARAMETERS
This section lists the parameters to be found in the set-up, with the alternative settings and their
meanings.
The default values are indicated in bold print.
4.3.2.1 CONFIGURATION MODE MENU PARAMETERS
Choice of code interpreter to be used.
Saves the emulation change made on line in EEPROM.
Determines the Draft type that can be activated via
SW and by default.
Determines the LQ type that can be activated via SW
and by default.
Measures the document width at the header or at the
first print line.
Width measurement tolerates the presence of dark
fields up to four inches wide.
Activates/deactivates the acoustic signal.
Data transmission/receiving rate (bit).
Data format: 7 or 8 bits.
Presence/type of parity control: none, odd, even.
Number of stop bits.
Data Set Ready managed/not managed by printer.
Must be set as on the connected system.
Data Carrier Detector managed/not managed by
printer. Must be set as on the connected system.
EMULATION IBM - OLIVETTI
EMULATION TEMPORARY
SELECTION PERMANENT
DRAFT SPEED: NORMAL - HIGH -
VERY HIGH
LQ TYPE: NLQ1 - NLQ2 - LQ2
PAPER WIDTH: FIRST LINE -
(ONLY PROGRAMMABLE
SCANNER
VERSION)
BUZZER Y - N
INTERFACE RS 232C - PARALLEL -
DUAL
- Only for the interface RS 232C
BAUD RATE: 9600 - 4800 - 2400 -
1200
BIT/CHAR: 7 - 8
PARITY: NONE - ODD -
EVEN
STOP BIT: 1 - 2
DSR: Y - N
DCD: Y - N
