683311W
6-8
6.4 PR2 SCANNER MAIN BOARD
The BAPR2 board can be configured with a double interface (as shown in the figure) or without parallel
interface connector and circuitry. The two board versions also have different codes.
6.4.1 BOARD VIEW AND LOCATION OF CONNECTORS
Fig. 6-4 PR2 Scanner Main Board Installed in the Printer
J18J14J15J19J16J13J12J6 J11
J5 J4 J3 J2 J1
J8
J7
