Olivetti PR2 - Disassembly: MICR Motor

Service Manual
683311W
9-19
9.3.2 DISASSEMBLING/REASSEMBLING THE MICR MOTOR
- Remove the case and assembly (section 9.3.1)
- Disconnect the cable motor from the board
- Loosen the two nuts (1) and remove the motor with related protection shield.
1
1
Fig. 9-18
