Olivetti PR2 - Page 119

Service Manual
683311W
6-11
1 TRF2B
2 TRF2A
3 TRF1B
4 TRF1A
1 VCC
2 CKMOT
3 DACOM
4 FAZMA
5 PMAGN
6 VERMA
7 RESE0
8 F2FDA
9 PIU12
10 GND
J12
(MAGNETIC BAND OPTION)
1 FOCOM
2 VCCAL2
3 LECOM
4 LEAL3
5 LECOM
6 FOCOM
7 VCCAL4
8 FOAL3
9 VCC
10 FOAN2
11 LEAN2
12 LEAN1
13 FOAL1
14 FOAN1
15 LEAL1
1 MAC21
2 MAC20
3 MAC11
4 MAC10
5 MAPH2
6 MAPH1
7 PIU35
8 PIU35
9 GND
10 GND
J11
(MAGNETIC BAND OPTION)
J1
(FRONT PHOTOSENSORS)
1 MR01A
2 MR01B
3 MR02A
4 MR02B
J9
(FEEDER MOTOR)
J3
(ROLLER MOTOR)
1 RBF2B
2 RBF2A
3 RBF1B
4 RBF1A
J7
(SCANNER MOTOR)
1 AINCI
2 GND
3 ANVCC
4 ME12F
5 GND
6 SICIF
7 GND
8 CLKCF
9 PILED
10 ALILED
J6
(SCANNER)
