Olivetti PR2 - PR2 MAGN Board Connector Signals

683311W
6-16
6.6.2.1 CONNECTOR SIGNALS
J1
(MAIN BOARD CONNECTION)
1 MAC21
2 MAC20
3 MAC11
4 MAC10
5 MAPH2
6 MAPH1
7 PIU35
8 PIU35
9 GND
10 GND
J2
(MAIN BOARD CONNECTION)
1 VCC
2 DAWRM
3 DACOM
4 FAZMA
5 GND
6 VERMA
7 RESE0
8 F2FDA
9 PIU12
10 GND
J3
(MAGNETIC MOTOR)
1 FAM0
2 FAM1
3 FAM2
4 FAM3
J5
(MAGNETIC HEAD)
1 WRI1
2 WRI0
3 GND
4 GND
5 LEO1
6 LEO0
J4
(MAGNETIC RESET PHOTO.)
1 VCC
2 VCC
3 LED1
4 FAZZ0
1 OUT1
2 GND
J6
(ADJUSTMENTS)
